IKO CRH101VBUU
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH10-1VBUU
Stud Diameter
7.938
mm
Outer Diameter
15.875
mm
Width
11.112
mm
Stud Diameter
7.938
mm
Thread
5/16-24
Length
7.938
mm
Maximum width
12.8
mm
Length
19.050
mm
Dimension
-
mm
Dimension
0.794
mm
Diameter
-
mm
Diameter
-
mm
Dimension
3.175
mm
Radius
0
mm
rs min.
0.397
mm
Min.Dimension related to the installation
11.112
mm
Maximum tightening torque
6.8
Nm
Basic dynamic load rating
6340
N
Basic static load rating
8530
N
Mass
23
g
