IKO CRH14VB
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH14VB
Stud Diameter
11.112
mm
Outer Diameter
22.225
mm
Width
12.700
mm
Stud Diameter
11.112
mm
Thread
7/16-20
Length
9.525
mm
Maximum width
14.6
mm
Length
22.225
mm
Dimension
6.35
mm
Dimension
0.794
mm
Diameter
4.762
mm
Diameter
2.381
mm
Dimension
4.762
mm
Radius
0
mm
rs min.
0.794
mm
Min.Dimension related to the installation
13.494
mm
Maximum tightening torque
17.6
Nm
Basic dynamic load rating
8710
N
Basic static load rating
12300
N
Mass
49
g
