CRH20VB
MORE +
CLOSE +

IKO CRH20VB

Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Hex Head,
(BRAND):IKO
(Availability):In Stock
(EMAIL):info@noksbearings.com

Detailed data of

CRH20VB

Order Number CRH20VB
Stud Diameter 19.050 mm
Outer Diameter 31.750 mm
Width 19.050 mm
Stud Diameter 19.050 mm
Thread 3/4-16 Length
15.875 mm
Maximum width 21.0 mm
Length 31.750 mm
Dimension 7.938 mm
Dimension 1.588 mm
Diameter 4.762 mm
Diameter 2.381 mm
Dimension 6.350 mm
Radius 0 mm
rs min. 1.588 mm
Min.Dimension related to the installation 24.209 mm
Maximum tightening torque 103.0 Nm
Basic dynamic load rating 23600 N
Basic static load rating 31700 N
Mass 176 g
