IKO CRH22VBUUR
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH22VBUUR
Stud Diameter
19.050
mm
Outer Diameter
34.925
mm
Width
19.050
mm
Stud Diameter
19.050
mm
Thread
3/4-16
Length
15.875
mm
Maximum width
21.0
mm
Length
31.750
mm
Dimension
7.938
mm
Dimension
1.588
mm
Diameter
4.762
mm
Diameter
2.381
mm
Dimension
6.350
mm
Radius
360
mm
rs min.
1.588
mm
Min.Dimension related to the installation
24.209
mm
Maximum tightening torque
103.0
Nm
Basic dynamic load rating
23600
N
Basic static load rating
31700
N
Mass
200
g
