IKO CRH24V
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Shielded, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH24V
Stud Diameter
22.225
mm
Outer Diameter
38.100
mm
Width
22.225
mm
Stud Diameter
22.225
mm
Thread
7/8-14
Length
19.050
mm
Maximum width
24.3
mm
Length
38.100
mm
Dimension
9.525
mm
Dimension
1.588
mm
Diameter
4.762
mm
Diameter
2.381
mm
rs min.
1.588
mm
Min.Dimension related to the installation
26.988
mm
Maximum tightening torque
162.0
mm
Basic dynamic load rating
28200
N
Basic static load rating
40100
N
Mass
296
g
