IKO CRH24VBUU
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Cylindrical Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH24VBUU
Stud Diameter
22.225
mm
Outer Diameter
38.100
mm
Width
22.225
mm
Stud Diameter
22.225
mm
Thread
7/8-14
Length
19.050
mm
Maximum width
24.3
mm
Length
38.100
mm
Dimension
9.525
mm
Dimension
1.588
mm
Diameter
4.762
mm
Diameter
2.381
mm
Dimension
7.938
mm
Radius
0
mm
rs min.
1.588
mm
Min.Dimension related to the installation
26.988
mm
Maximum tightening torque
162.0
Nm
Basic dynamic load rating
28200
N
Basic static load rating
40100
N
Mass
296
g
