IKO CRH64VBUUR
Heavy Duty Inch Series Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Sealed, Hex Head,
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
CRH64VBUUR
Stud Diameter
50.800
mm
Outer Diameter
101.600
mm
Width
57.150
mm
Stud Diameter
50.800
mm
Thread
2-12
Length
38.100
mm
Maximum width
59.4
mm
Length
88.900
mm
Dimension
19.05
mm
Dimension
0.800
mm
Diameter
6.35
mm
Diameter
3.175
mm
Dimension
19.050
mm
Radius
760
mm
rs min.
2.381
mm
Min.Dimension related to the installation
64.691
mm
Maximum tightening torque
2190.0
Nm
Basic dynamic load rating
142000
N
Basic static load rating
317000
N
Mass
4960
g
