IKO NUCF101R
Cylindrical Roller Metric Cam Follower, Full Complement, High Carbon Steel, Crowned Outer Ring, Shielded, Screw Driver Slot,
(BRAND)：IKO
(Availability)：In Stock
Order Number
NUCF10-1R
Stud Diameter
10
Outer Diameter
26
Width
12
Stud Diameter
10
Thread
M10x1.25
Length
12
Maximum width
13.2
Max.Total length
36.2
Length
23.0
Dimension
-
Dimension
0.6
Diameter
4
Diameter
-
Min.Dimension related to the installation
12
Maximum tightening torque
13.8
Basic dynamic load rating
10400
Basic static load rating
11500
Max.Static allowable load
9210
Mass
58
